MINI-SYS-PS-100-240AC/24DC/1.5
Safety and warning notes
The power supply units are built-in devices. The device may only be installed and put into operation by qual-
ified personnel. The corresponding national regulations (e.g. VDE, DIN) must be observed.
Danger!
Components with dangerously high voltage and high stored energy are located in the device!
Never carry out work on live parts!
Depending on the ambient temperature and the load, the housing can become very hot!
Before startup please ensure:
The mains connection has been carried out by a competent person and protection against electric
shock is guaranteed!
The device can be disconnected outside the power supply unit in accordance with the regulations as
in EN 60950 (e.g. through primary side line protection)!
All feed lines are sufficiently protected and dimensioned!
All output lines are dimensioned according to the maximum output current of the device or separately
protected!
Sufficient convection is guaranteed!
Installation
In order to guarantee sufficient convection, we
recommend observing the following minimum
distance to other modules: 5 cm in a vertical di-
rection and 0 cm in a horizontal direction.
The power supply unit can be snapped onto all
DIN rails in acc. with EN 60715. They must be
horizontal (connecting terminal blocks above
OU 13
2 V D 2 14
4
0V V 1.5
C/1
C/2
40A
